Well Equipped
Features:
- Hydraulic furling mainsail
- Bow thruster
- 4x solar panel
- Raymarine i70
- Evo pilot
- E7 chart plotter
- AIS
- Epirb
- Generator
- Windlass
General
Rudder: Rudder with a skeg
Steering System: Whitlock pedestal (rod-connection) and stainless steel steering wheel
Windows: Gebo deck hatches (craquelee - in fore cabin and aft cabin with curtains) and port holes
Other:
- White polyester hull with blue striping
- Teak rubbing strake around the hull provided with a stainless steel protection strip
- Teak on the cockpit seats and teak on the cockpit floor
- The underwater hull has been provided with 7 layers of Cupper Coat Epoxy
- This yacht was built according to Lloyd's regulation
Maintenance History
Done in 2015:
- All hull fittings, all sea cocks, all hose clamps and all hoses have been renewed
Done in 2017:
Accommodation
Material, Colours: Teak interior
Cabins: Fore cabin and aft cabin
Cooker & Fuel: Techimpex
Other:
- Neptune mattresses in the aft cabin
- The blue rib cloth upholstery needs to be renewed
- Folding wooden Lee Cloths for both saloon seats (to use when sleeping on the saloon seat during sailing)
- Almost all of the interior lights are LED
- A thick rubber insulation mat has been glued on the inside of the hull (starting at the waterline)
Engine, Electrics, Water
Power: 46.23 kw
Fuel Tanks: Fuel tank with 5 internal walls and inspection openings
Propulsion: 3 blade Autoprop (2003) Feathering propeller and a spare fixed 3 bladed propeller
Dynamo: 2017: Overhauled
Solar Panel: 2015: 1x 100 Watt, 2x 80 Watt and 1x 50 Watt (all tilting) with 2x Victron Blue Solar Charger MPPT 75-15
Water System: Electric water pressure system (the water pump has been renewed in 2017) and a foot pump at the galley
Hot Water: Hot water boiler (heated by the engine or by 220 Volt shore power -> the 220 Volt heating element is broken, so currently not functioning)
Water Tank & Material: (in 2 tanks)
Shorepower: Fixed connection with a circuit breaker
Other:
- Double equipped Vetus fuel filter system with water separator is reversible
- A water greased stainless steel propeller shaft
- 2x Vetus spare fuel filter
- Several small spare parts (V-belt/impellor)
- Portable fuel filter (funnel)
- Several spare toilet parts
- Several 220 Volt sockets
Done in 2014:
- New fuel lift pump
- The engine water pump (renewed in 2001) for the external cooling water system has been overhauled
Done in 2015:
- Fuel tank has been cleaned
- All fuel hoses have been renewed
Done in 2017:
- Engine maintenance
- All fuel injectors have been checked and cleaned
Rig and Sails
Sailplan Type: Mast head rigged
Spars, Stays: Reckmann mast, boom, tackle boomvang, stainless steel stays with a double set of spreaders, removable babystay and a manual Nemo backstay tensioner
Winches: Enkes winches: 2x ST, 2x ST, 1x 26 and 1x 22
Genoa: 2x furling genoa (1x reasonable condition and 1x old)
Jib: Stay jib (for the inner fore stay)
Furling Foresail: 2015: Furlex
Halfwinder, Bollejan: Red/white Booster/Half winder (a flying sail)
Number of Masts: Hydraulic Reckmann stow-a-way mast
Other:
- Folding Mast Steps mounted on the mast all the way to the masthead
- Aluminium spinnaker pole
- Removable stainless steel bow sprit
- Removable Dyneema preventive Jack stays
Done in 2015:
- The hydraulic oil has been renewed
- All stays have been checked, pulled and certified
- The main stays, the inner fore stay and the backstay have been renewed
- Tackle line of the boomvang and the outhaul line of the furling mainsail have been renewed
- The genoa halyard, the storm jib halyard and the spinnaker halyard have been renewed
Navigation and Electronics
Rudder Position Indicator: Via autopilot
Weatherfax/Navtex: (it doesn't receive information, so has to be repaired/renewed)
Charts, Guides: 2014: Navionics: 1x Europe and 1x Caribbean
Other: Done in 2014:
- Complete new Raymarine Bus system installed
Done in 2015:
- Stainless steel antenna pole mounted on the stern
Equipment
Anchor Windlass: 2017: Lofrans windlass (up/down)
Swimming Ladder: Extended stainless steel boarding ladder with teak steps
Swimming Platform: Stainless steel bracket frame provided with teak slats
Sea Rails, Pushpit, Pulpit: Stainless steel stanchions, pushpit, pulpit, double-wired guardrail with amidships passages
Other:
- Plastic outboard engine bracket on the pushpit
- Bosuns chair
Safety
Gas Bottle Locker with Drain: Gas bun for 2 bottles. The gas hoses have been renewed in 2015
Other:
- Emergency tiller
- Life-Sling
- Life-Lines on deck
- Black cone
