OFFERED BY
Northrop and Johnson
LOCATION
Gocek, Turkey
YEAR
2016
LENGTH
100.72 ft.
Condition
Used
Name
ZEEMAR
Year
2016
Make & Model
Aydos Yat Custom
Boat type
Power
Length
100.72 ft.
Fuel Type
Diesel
Location
Gocek, Turkey
Beam
24.93 ft.
Cabins
5
Draft
6.56 ft.
Built by Aydos
Year 2016
Length 100’ (30,70m)
Beam 24’9’’ (7,60m)
Draft 6’5’’ (2m)
Classification RINA Commercial Unrestricted
Flag Cook Island
Gross tonnage 245
Net tonnage 72
Displacement 260 ton @half load
Designer Alpaslan Tekogul
Naval Architect Alpaslan Tekogul
Interior Designer Ali Gez and ICT Yachts
Built by Aydos
Year 2016
Length 100’ (30,70m)
Beam 24’9’’ (7,60m)
Draft 6’5’’ (2m)
Classification RINA Commercial Unrestricted
Flag Cook Island
Gross tonnage 245
Net tonnage 72
Displacement 260 ton @half load
Designer Alpaslan Tekogul
Naval Architect Alpaslan Tekogul
Interior Designer Ali Gez and ICT Yachts
Speed 13,0 knots
Range 1100Nm @8,5 knots
Fuel capacity 2,113 Gal (8000 Lt)
Water capacity 793 Gal (3000 Lt)
Black water capacity 528 Gal (2000 Lt)
Grey water capacity 528 Gal (2000 Lt)
Fuel consumption 230 Lt @ 13 knots Max speed
50 Lt @ 8 knots
Speed 13,0 knots
Range 1100Nm @8,5 knots
Fuel capacity 2,113 Gal (8000 Lt)
Water capacity 793 Gal (3000 Lt)
Black water capacity 528 Gal (2000 Lt)
Grey water capacity 528 Gal (2000 Lt)
Fuel consumption 230 Lt @ 13 knots Max speed
50 Lt @ 8 knots
Engines 2x MAN 560HP
Engine model MAN 560HP @2100RPM
Engine hours 1350
Fuel Diesel
Fuel Consumption 230 Lt. at 13kn
80 Lt. at 10kn
50 Lt. at 8,5kn
Propulsion Conventional
Gearboxes ZF
Steering Power Assisted Hydraulic
Stabilizers Wesmar Hydraulic Fin Zero Speed
Dampers 2x ELL/APP Exhaust and
Engines 2x MAN 560HP
Engine model MAN 560HP @2100RPM
Engine hours 1350
Fuel Diesel
Fuel Consumption 230 Lt. at 13kn
80 Lt. at 10kn
50 Lt. at 8,5kn
Propulsion Conventional
Gearboxes ZF
Steering Power Assisted Hydraulic
Stabilizers Wesmar Hydraulic Fin Zero Speed
Dampers 2x ELL/APP Exhaust and
Generators 2x 55Kw Auto Sync Caterpillar Gens
Generator hours 2053
Generators 2x 55Kw Auto Sync Caterpillar Gens
Generator hours 2053
Electricity 24v DC/380+220v AC electrical system
Shore power GLENDENNING
Electricity 24v DC/380+220v AC electrical system
Shore power GLENDENNING
Service Batt. 12x Shonennein Gel 12V
1080 Amp. /2022
Start Batt. 4x Odyssey AGM 12V
170 Amp. /2022
Gen. Batt. 4x Odyssey AGM 12V
100 Amp. /2022
Emer. Batt. 2x Odyssey AGM 12V
220 Amp. /2022
VHF Batt. Victron Gel 12V
126 Amp. /2022
Battery Charger Victron Battery Chargers
and Convertors
Battery Charger
/Inverters Victron Charger 3 Victron Multiplus
Wipers EXALTO
Service Batt. 12x Shonennein Gel 12V
1080 Amp. /2022
Start Batt. 4x Odyssey AGM 12V
170 Amp. /2022
Gen. Batt. 4x Odyssey AGM 12V
100 Amp. /2022
Emer. Batt. 2x Odyssey AGM 12V
220 Amp. /2022
VHF Batt. Victron Gel 12V
126 Amp. /2022
Battery Charger Victron Battery Chargers
and Convertors
Battery Charger
/Inverters Victron Charger 3 Victron Multiplus
Wipers EXALTO
Air Conditioner Cruisair
180,000 BTU chiller
with fan coils
Fresh Air Makeup Cruisair
Air Conditioner Cruisair
180,000 BTU chiller
with fan coils
Fresh Air Makeup Cruisair
Bow Thruster Wesmar 35kW Hydraulic
Stern Thruster None
Water makers Idromar 280lt/hour
Seafari 200lt/hour
Octomarine Water Softener
Jowa 15 Ionizer
Propellers Teignbridge 5 Blade
Shafts Stainless steel shafts
Rudder angle indicators Yes
Fuel filters Separ Filters
Fuel oil polishing Reverso Polishing System
Fire bilge pump Gianneschi
Emerg. Fire pump El Pompa
Boilers Quick Nautic Boiler 100L
Quick Nautic Boiler 100L
Sewage treatment Tecnicomar Ecomar 8 4000lt/day
WC’s Tecma Toilet Systems /2022
Bow Thruster Wesmar 35kW Hydraulic
Stern Thruster None
Water makers Idromar 280lt/hour
Seafari 200lt/hour
Octomarine Water Softener
Jowa 15 Ionizer
Propellers Teignbridge 5 Blade
Shafts Stainless steel shafts
Rudder angle indicators Yes
Fuel filters Separ Filters
Fuel oil polishing Reverso Polishing System
Fire bilge pump Gianneschi
Emerg. Fire pump El Pompa
Boilers Quick Nautic Boiler 100L
Quick Nautic Boiler 100L
Sewage treatment Tecnicomar Ecomar 8 4000lt/day
WC’s Tecma Toilet Systems /2022
Accommodation for
GUESTS 10
CREW 6
Accommodation for
GUESTS 10
CREW 6
Galley Custom Made Full freezer
and full height refrigerator
Galley Electrolux Full Heigh Refrigerator
Galley Electrolux Cooktop, Wine cooler,
Ratiobol Oven, Electrolux Aspirator
Sundeck Bar Isotherm fridge, icemaker, and sink
Aft bar Isotherm fridge, icemaker
Crew mess Fridge, Sink and Miele Dishwasher
Laundry Miele Washer and Miele Dryer
Galley Custom Made Full freezer
and full height refrigerator
Galley Electrolux Full Heigh Refrigerator
Galley Electrolux Cooktop, Wine cooler,
Ratiobol Oven, Electrolux Aspirator
Sundeck Bar Isotherm fridge, icemaker, and sink
Aft bar Isotherm fridge, icemaker
Crew mess Fridge, Sink and Miele Dishwasher
Laundry Miele Washer and Miele Dryer
COMMUNICATION EQUIPMENT
► Simrad Communication Systems
NAVIGATION EQUIPMENT
► SIMRAD 2 x 16” Charter Plotter, Depth Sounder,
► SIMRAD Autopilot , VHF with AIS
► Navtex
► 2x Simrad 12 screen in Captains cabin and Crew mess
ENTERTAINMENT EQUIPMENT
► Intelliain Sat TV 60 cm
Main salon 55” LED TV, Bose System
Sun deck Martin Audio
Owners cabin 55” LED TV, martin Audio
Guest Cabins 43” LED TV, Sonos Speaker
Captain’s cabin
and guests Sonos Speaker
Wifi Systems
► High range 4 Antennas with Peplink Systems Wifi System
throughout the yacht
COMMUNICATION EQUIPMENT
► Simrad Communication Systems
NAVIGATION EQUIPMENT
► SIMRAD 2 x 16” Charter Plotter, Depth Sounder,
► SIMRAD Autopilot , VHF with AIS
► Navtex
► 2x Simrad 12 screen in Captains cabin and Crew mess
ENTERTAINMENT EQUIPMENT
► Intelliain Sat TV 60 cm
Main salon 55” LED TV, Bose System
Sun deck Martin Audio
Owners cabin 55” LED TV, martin Audio
Guest Cabins 43” LED TV, Sonos Speaker
Captain’s cabin
and guests Sonos Speaker
Wifi Systems
► High range 4 Antennas with Peplink Systems Wifi System
throughout the yacht
► 4,20 Joker Boat with 40HP Tender
► 4,20 Joker Boat with 40HP Tender
Steering System DATA Hydraulic Steering System
Windlass 2x Hidromar Vertical Hydraulic
Anchors 2x 230kg Stainless Steel HHP
Chains 2x EVREN U1 16mm
150mm + 200mm
Capstan 4x Hydraulic Capstan
Underwater Lights 4X Underwater lights
Pasarelle Custom-made Pasarelle
Sliding Door 2x Bofor
Pantograph Doors Bofor Doors
Windows Class approved Windows
Steering System DATA Hydraulic Steering System
Windlass 2x Hidromar Vertical Hydraulic
Anchors 2x 230kg Stainless Steel HHP
Chains 2x EVREN U1 16mm
150mm + 200mm
Capstan 4x Hydraulic Capstan
Underwater Lights 4X Underwater lights
Pasarelle Custom-made Pasarelle
Sliding Door 2x Bofor
Pantograph Doors Bofor Doors
Windows Class approved Windows
► Custom made Alarm and Monitoring System
► Novec Fire Extinguishing System
► Seckin Fire Extinguisher portable
► 6x Cameras
► 2x SOLAS B10
► Custom made Alarm and Monitoring System
► Novec Fire Extinguishing System
► Seckin Fire Extinguisher portable
► 6x Cameras
► 2x SOLAS B10
JOB AREA JOB LOCATION JOB DESCRIPTION
Paint Exterior Polishing only excluding Ceramic coating
Carpentry Sundeck Replacing glass windshield
Carpentry Upperdeck Saloon Adding glass on both side of the wall where old ESPA letters are
Carpentry Upperdeck Saloon Replacement of the Carpets with parquets flooring
Carpentry Upperdeck Saloon Changing the color of the BEIGE LACQUER on the sides
Carpentry Upperdeck Saloon Adding wall in the middle of two pillars so that TV could be added
Carpentry Upperdeck Saloon Reorganizing AC blow out
Carpentry Upperdeck Saloon Finding a solution for the two-walnut strip on the ceiling
Carpentry Upperdeck Saloon Adding L Shaped seating on the STBD side
Carpentry Upperdeck Saloon Adding pantry station on the port side
Carpentry Upperdeck Saloon Adding Captain’s Cabin
Carpentry Upperdeck Wheelhouse Changing the color of the seating
Carpentry Upperdeck Wheelhouse Rebuilding the sofa
Carpentry Maindeck Saloon Changing the back piece behind the TV
Carpentry Maindeck Saloon Replacement of the carpets with parquets flooring
Carpentry Maindeck Saloon Replacement of ceiling
Carpentry Maindeck Saloon Changing the color of the BEIGE LACQUER on the sides
Carpentry Maindeck Saloon Adding big wine cooler to the back of the day head
Carpentry Maindeck Master cabin Redesigning of the master cabin all included
Carpentry Maindeck Master cabin Replacement of the carpets with parquet flooring
Carpentry Maindeck Master cabin Bathroom reorganizing
Carpentry Lowerdeck Crew Galley Move the sink to the port side and try to add dishwasher from the main galley
Carpentry Lowerdeck Crew Mess Shortened the length of the messroom, reorganized to better accommodate people
Carpentry Lowerdeck Crew Mess Top Loading freezer instead of cold room
Carpentry Lowerdeck Crew Bath Adding sliding doors on both side of the bathroom and closing off the current entrance
Carpentry Lowerdeck Crew FWD Widen the bottom bunk of each cabin
Carpentry Lowerdeck Port Twin Cabin Making each bed wider 5 to 10cm and reorganize the night table
Banyo Lowerdeck Capt. Cabin Change the configuration of the bathroom so that separate shower could be fitted
Banyo Lowerdeck Crew Bath Reorganize the forward bathroom so that separate shower could be integrated
Paint Exterior Black paint on the connection fwd bulwark
Paint Exterior Underwater paint and replacement of anodes
Paint Exterior Painting exterior furniture
Paint Exterior Garage door paint repairs
Upholstery Sundeck Adding tent shading
Upholstery Upperdeck Wheelhouse Changing the cushions, more dense cushions added
Upholstery Maindeck Saloon Replacing the u-shaped cushions
Paint Upperdeck Exterior Vinyl wrapping / painting the side in black color
Paint Maindeck Exterior Vinyl wrapping / painting the side in black color
Carpentry Sundeck RINA stability analysis
Stainless Steel Upperdeck Exterior Adding handrail on the port side of the stairs
Carpentry Upperdeck Exterior Changing the al-fresco dining table to accommodate 8-10 guests with chairs
Composite Upperdeck Exterior Adding multiplex styled shading and poles
RINA Upperdeck Saloon Captain’s Cabin RINA Approval
Purchasing Upperdeck Wheelhouse Replacement of steering wheel
Stainless Steel Upperdeck Wheelhouse Adding leaning post
Carpentry Maindeck Exterior Changing the table pedestal and the top
Purchasing Maindeck Exterior Adding chairs
Purchasing Maindeck Saloon Changing TV
Carpentry Maindeck Saloon Replacement of interior dining table
Carpentry Maindeck Saloon Replacing the saloon coffee table
Carpentry Lowerdeck Exterior Garage door replaced with lighter material
Project General RINA 5 Year survey
Project General RINA Yearly Survey
Carpentry Exterior Adding track rail above the master cabin windows
Carpentry Exterior Yacht name on the garage door electrical with plexi
Carpentry Maindeck Master cabin Changing the blinds and curtains with the black out shutter and the blinds
Carpentry Lowerdeck Cabins Changing the blinds and curtains with the black out shutter and the blinds
Carpentry Sundeck Teak Replacement
Carpentry Sundeck Adding low profile bar with fridge
Purchasing All Top loading Freezer, faucets, Lambs, Strip lights, Steering Wheel, Dishwasher, Refrigerator, Exterior cushions,
2 x Icemaker, 2 x Half Height Fridge, Outlets, Grill, 12 Chairs, 4 Bar stool, 2 x Loose Sofa, 3 x TV, Wine cooler, Oven,
Speakers, Crockery, Cutlery, Mattress, Linens, Interior Furnishing, Chinaware, Towels, Shoes,Crew Uniforms, Crew Shoes, Underwater Lights if necessary
Carpentry Sundeck Reorganizing current sink area with grill and fridge
Carpentry Sundeck Adding bar seats
Carpentry Sundeck Adding L-seating area on the starboard side with coffee table
Carpentry Sundeck Removal of helm station
Carpentry Upperdeck Exterior Teak Replacement
Carpentry Upperdeck Exterior Reorganizing aft seating with widened seating USB and Cupholder, cozy style, walkaround type
Carpentry Upperdeck Exterior Removal of Bar unit
Carpentry Upperdeck Saloon Opening the glass area
Carpentry Maindeck Exterior Teak Replacement
Carpentry Maindeck Exterior Adding bar unit with fridge, icemaker with its own forward tank
Carpentry Lowerdeck Exterior Teak Replacement Swimming platform and garage
Carpentry Exterior Complete RINA Remarks on the exterior and interior remedial work
Carpentry Exterior Garage door redoing
Carpentry Sundeck Adding forward seating area with sunbrella cushions
AV/IT Sundeck Adding Stereo system
AV/IT Sundeck Adding two powerful wifi antennas on the arch
AV/IT Sundeck Adding Peplink access points
AV/IT Upperdeck Saloon Adding Peplink access points
AV/IT Maindeck Exterior Adding Stereo system
AV/IT Maindeck Saloon Adding Stereo system
AV/IT Maindeck Saloon Adding Peplink access points
AV/IT Lowerdeck Corridor Adding Peplink access points
AV/IT Lowerdeck Cabins Adding Stereo system
Plumbing All All Plumbing
Mechanic All All Mechanic excluding hydraulic and stabilizer service and other services
Electrical All All Electrical
JOB AREA JOB LOCATION JOB DESCRIPTION
Paint Exterior Polishing only excluding Ceramic coating
Carpentry Sundeck Replacing glass windshield
Carpentry Upperdeck Saloon Adding glass on both side of the wall where old ESPA letters are
Carpentry Upperdeck Saloon Replacement of the Carpets with parquets flooring
Carpentry Upperdeck Saloon Changing the color of the BEIGE LACQUER on the sides
Carpentry Upperdeck Saloon Adding wall in the middle of two pillars so that TV could be added
Carpentry Upperdeck Saloon Reorganizing AC blow out
Carpentry Upperdeck Saloon Finding a solution for the two-walnut strip on the ceiling
Carpentry Upperdeck Saloon Adding L Shaped seating on the STBD side
Carpentry Upperdeck Saloon Adding pantry station on the port side
Carpentry Upperdeck Saloon Adding Captain’s Cabin
Carpentry Upperdeck Wheelhouse Changing the color of the seating
Carpentry Upperdeck Wheelhouse Rebuilding the sofa
Carpentry Maindeck Saloon Changing the back piece behind the TV
Carpentry Maindeck Saloon Replacement of the carpets with parquets flooring
Carpentry Maindeck Saloon Replacement of ceiling
Carpentry Maindeck Saloon Changing the color of the BEIGE LACQUER on the sides
Carpentry Maindeck Saloon Adding big wine cooler to the back of the day head
Carpentry Maindeck Master cabin Redesigning of the master cabin all included
Carpentry Maindeck Master cabin Replacement of the carpets with parquet flooring
Carpentry Maindeck Master cabin Bathroom reorganizing
Carpentry Lowerdeck Crew Galley Move the sink to the port side and try to add dishwasher from the main galley
Carpentry Lowerdeck Crew Mess Shortened the length of the messroom, reorganized to better accommodate people
Carpentry Lowerdeck Crew Mess Top Loading freezer instead of cold room
Carpentry Lowerdeck Crew Bath Adding sliding doors on both side of the bathroom and closing off the current entrance
Carpentry Lowerdeck Crew FWD Widen the bottom bunk of each cabin
Carpentry Lowerdeck Port Twin Cabin Making each bed wider 5 to 10cm and reorganize the night table
Banyo Lowerdeck Capt. Cabin Change the configuration of the bathroom so that separate shower could be fitted
Banyo Lowerdeck Crew Bath Reorganize the forward bathroom so that separate shower could be integrated
Paint Exterior Black paint on the connection fwd bulwark
Paint Exterior Underwater paint and replacement of anodes
Paint Exterior Painting exterior furniture
Paint Exterior Garage door paint repairs
Upholstery Sundeck Adding tent shading
Upholstery Upperdeck Wheelhouse Changing the cushions, more dense cushions added
Upholstery Maindeck Saloon Replacing the u-shaped cushions
Paint Upperdeck Exterior Vinyl wrapping / painting the side in black color
Paint Maindeck Exterior Vinyl wrapping / painting the side in black color
Carpentry Sundeck RINA stability analysis
Stainless Steel Upperdeck Exterior Adding handrail on the port side of the stairs
Carpentry Upperdeck Exterior Changing the al-fresco dining table to accommodate 8-10 guests with chairs
Composite Upperdeck Exterior Adding multiplex styled shading and poles
RINA Upperdeck Saloon Captain’s Cabin RINA Approval
Purchasing Upperdeck Wheelhouse Replacement of steering wheel
Stainless Steel Upperdeck Wheelhouse Adding leaning post
Carpentry Maindeck Exterior Changing the table pedestal and the top
Purchasing Maindeck Exterior Adding chairs
Purchasing Maindeck Saloon Changing TV
Carpentry Maindeck Saloon Replacement of interior dining table
Carpentry Maindeck Saloon Replacing the saloon coffee table
Carpentry Lowerdeck Exterior Garage door replaced with lighter material
Project General RINA 5 Year survey
Project General RINA Yearly Survey
Carpentry Exterior Adding track rail above the master cabin windows
Carpentry Exterior Yacht name on the garage door electrical with plexi
Carpentry Maindeck Master cabin Changing the blinds and curtains with the black out shutter and the blinds
Carpentry Lowerdeck Cabins Changing the blinds and curtains with the black out shutter and the blinds
Carpentry Sundeck Teak Replacement
Carpentry Sundeck Adding low profile bar with fridge
Purchasing All Top loading Freezer, faucets, Lambs, Strip lights, Steering Wheel, Dishwasher, Refrigerator, Exterior cushions,
2 x Icemaker, 2 x Half Height Fridge, Outlets, Grill, 12 Chairs, 4 Bar stool, 2 x Loose Sofa, 3 x TV, Wine cooler, Oven,
Speakers, Crockery, Cutlery, Mattress, Linens, Interior Furnishing, Chinaware, Towels, Shoes,Crew Uniforms, Crew Shoes, Underwater Lights if necessary
Carpentry Sundeck Reorganizing current sink area with grill and fridge
Carpentry Sundeck Adding bar seats
Carpentry Sundeck Adding L-seating area on the starboard side with coffee table
Carpentry Sundeck Removal of helm station
Carpentry Upperdeck Exterior Teak Replacement
Carpentry Upperdeck Exterior Reorganizing aft seating with widened seating USB and Cupholder, cozy style, walkaround type
Carpentry Upperdeck Exterior Removal of Bar unit
Carpentry Upperdeck Saloon Opening the glass area
Carpentry Maindeck Exterior Teak Replacement
Carpentry Maindeck Exterior Adding bar unit with fridge, icemaker with its own forward tank
Carpentry Lowerdeck Exterior Teak Replacement Swimming platform and garage
Carpentry Exterior Complete RINA Remarks on the exterior and interior remedial work
Carpentry Exterior Garage door redoing
Carpentry Sundeck Adding forward seating area with sunbrella cushions
AV/IT Sundeck Adding Stereo system
AV/IT Sundeck Adding two powerful wifi antennas on the arch
AV/IT Sundeck Adding Peplink access points
AV/IT Upperdeck Saloon Adding Peplink access points
AV/IT Maindeck Exterior Adding Stereo system
AV/IT Maindeck Saloon Adding Stereo system
AV/IT Maindeck Saloon Adding Peplink access points
AV/IT Lowerdeck Corridor Adding Peplink access points
AV/IT Lowerdeck Cabins Adding Stereo system
Plumbing All All Plumbing
Mechanic All All Mechanic excluding hydraulic and stabilizer service and other services
Electrical All All Electrical
Cruising Speed
11 Knots
Engine Count
0
Max Speed Knots
13
HULL
Hull Material
Wood
Hull Shape
Displacement
ELECTRICAL EQUIPMENT
Air Conditioning
Yes
ACCOMMODATION
Crew Berths
6
Crew Cabins
0
OTHER
Double Berths
3
Single Berths
4
Displacement(kgs)
165
Range
1100
Fuel Capacity Gal
2113
Fuel Tanks Capacity
8000 liters
Gross Tonnage
245
No of Heads
0
Holding Tank Gal
2113
Num Sleeps
10
Water Capacity Gal
2113
Water Tanks Capacity
8000 liters
Twin Berths
2
Displacement Type
tonnes
Holding Tanks Capacity
0 liters
The Aydos Yat Custom is 100 feet long that boasts a 25 feet beam and can hold up to 2113 gallons of fuel and 2113 gallons of water. This 2016 diesel Aydos Yat Custom is capable of reaching a maximum speed of 13 knots and a cruising speed of 11 Knots. The Aydos Yat Custom is made of wood, has 6 beds in 0 cabins . This vessel comes equipped with air conditioning .
