NEW PRICE DROP - OWNER WANTS IT SOLD
The Crowther is named after the legendary Australian boat designer and builder Lock Crowther. His first boat was a trimaran built in 1959 while he was still a teenager. Over 2500 boats were built using his various designs. After his death in 1993, his son took over the business, which is when this vessel was built. Crowther Cats are know for applying innovative materials at the time, like GRP-foam sandwich construction, and concepts like wave piercing bows.
Originally this design was a 40ft catamaran, and then in 1997 they launched an extended version by adding 3ft to the stern, with a comfortable swim platform.
Delivery in Puerto Montt or Lima, Peru. Other options can be negotiated.
Boat Name
RATAPLAN
Specs
- Builder: Alwoplast, Chile
- Designer: Lock Crowther
- Flag of Registry: Chile
- Keel: Other
- Hull Shape: Catamaran
Dimensions
- LOA: 43 ft 0 in
- Beam: 21 ft 0 in
- Maximum Draft: 2 ft 7 in
- Displacement: 17636 lbs Dry Load
- Bridge Clearance: 60 ft 0 in
- Headroom: 6 ft 7 in
- Freeboard: 2 ft 0 in
- Dry Weight: 17636 lbs
Engines
- Total Power: 60 HP
- Engine 1:
- Engine Brand: YANMAR
- Year Built: 2010
- Engine Model: 3YM30
- Engine Type: Inboard
- Engine/Fuel Type: Diesel
- Location: Starboard
- Engine Hours: 700
- Propeller: 3 blade propeller
- Drive Type: Sail drive
- Engine Power: 30 HP
- Engine 2:
- Engine Brand: YANMAR
- Year Built: 2010
- Engine Model: 3YM30
- Engine Type: Inboard
- Engine/Fuel Type: Diesel
- Location: Port
- Engine Hours: 700
- Propeller: 3 blade propeller
- Drive Type: Sail drive
- Engine Power: 30 HP
Cruising Speed: 7 knots @ 2000 RPM
Maximum Speed: 9 knots
Tanks
- Fresh Water Tanks: Fiberglass (132 Gallons)
- Fuel Tanks: (74 Gallons)
- Holding Tanks: Fiberglass (10 Gallons)
Accommodations
- Number of single berths: 1
- Number of double berths: 4
- Number of cabins: 4
- Number of heads: 2
- Seating Capacity: 8
Electronics
- Depthsounder
- Log-speedometer
- Wind speed and direction
- Navigation center
- Plotter
- Autopilot - Includes a handheld remote
- Compass
- GPS
- VHF
- Radar
- Radar Detector
- Computer - iPad with charts connected to Raymarine via Bluetooth
- TV set
- DVD player
- Radio
- CD player
- Cockpit speakers
Sails
- Fully battened mainsail
- Storm jib
- Spinnaker
Rigging
- Steering wheel
- Tiller - Emergency tiller
Inside Equipment
- Electric bilge pump
- Manual bilge pump
- Battery charger
- Air compressor - for inflating dinghy and fenders
- Hot water
- Sea water pump
- Oven
- Marine head - 2 manual heads
- Electric head - One
- Refrigerator
Electrical Equipment
- Shore power inlet - 60 ft 15 amp cord
- Generator - 2kW Honda 2 stroke
- Inverter - 12 V to 220 Volts
- Electrical Circuit: 220V
Outside Equipment/Extras
- Cockpit cushions
- Cockpit table - Hardwood table
- Swimming ladder
- Cockpit shower
- Outboard engine brackets
- Davits
- Radar reflector
- Tender - Two 10.5 ft dinghies. One hard bottom, one soft bottom
- Liferaft
- Total Liferaft Capacity: 4
- Electric windlass
Covers
- Bimini Top - Connects Hardtop to Radar arch
- Mainsail cover
- Lazyjacks
DIMENSIONS AND DETAILS
- Rataplan (Lock Crowther Design)
- Built 1997 (Full Overhaul 2010)
- First year of the extended 3ft stern with swim platform
- Loa: 13,05 m (42.8 ft)
- Beam: 6,35 m (20.8 ft)
- Draft: 0,8 m (2.6 ft)
- Mainsail Full batten 61 m² (656 ft²) Jib 29 m² (312 ft²) Working jib 12,8 m² (138 ft²)
- Fiberglass (Diviny Cell)
- Displacement 22.000 lbs
- Factory Alwoplast, Valdivia, Chile
CONSTRUCTION
- Polyester and high quality anti-osmotic resin FRP construction
- Balsa core hull, solid laminate under water line, white gel coat, Balsa core bridge deck and deck, gel coat, solid laminate inner liners
- Laminated marine plywood bulkheads
- Shallow draft hull no keel (see photos) with Daggerboards
SAILS AND STANDING RIGGING
- 1 Full batten 61 m² (650 ft²) (Dacron® full batten mainsail (Lidgard Sail from New Zealand, New in 2010)
- 1 Jib 29 m² (310 ft²) (furling genoa UV protection. Working jib 12,8 m² (138 ft²)
- 14 m /62’4” aluminium mast without mainsail track and ball-bearing battcars
- 2 Double spreader rig
- 1 anodized aluminium boom
- 2 high shrouds with chafeguards
- 2 lower shrouds with chafeguards
- 1 forestay furler 400
- 2 mainsail lazy-jacks
- Standing Rigging is original from Germany. In case replacement is needed, Alwoplast has quoted $11,000.
- Jib Furler and forestay foil is new from 2011.
HARDWARE
- 8 mooring cleats
- Lewmar H3 Anchor Electric Windlass in anchor locker
- 3 Manual Winches: 40 Harken STC
- Trampolín (France) (Bow safety net with knot-less nylon netting)
- Anchors: Delta (25 kg / 55 lb), Bruce (16 kg / 35 lb) Fortress (7 kg / 15.4 lbs, aluminum)
AFT COCKPIT
- Large cockpit usable as deck salon
- Removable varnished small cockpit table
ENGINES AND PROPELLERS
- Two 30 HP sail drive SD 20 (HP saildrive diesel engines. Yanmar 3YM30 ea. With Engine controls at helm station)
- Engine: 2 Yanmar 30 HP Model 3YM30 (NEW in 2010) currently with 700 Hours
- 2 16.5" Gory Propellers, 3 blades (2015)
- 8 knots at 2500 rpm and 3 liters per hour (0.79 gallons/hr)
- Soundproofed engine compartments, soundproof access panels
- 2 RACOR Sea water filter
- 2 x 140 liter (37 gal.) Stainless steel fuel tanks
- Six 60 liter (15.8 gal) jerry cans for diesel.
PLUMBING
- 132 gal: 2 x 66 Jabsco (2 water tank pressurized freshwater system).
- 2 Hot water tanks (10 gallons ea.)
ELECTRONICS
- Chart Plotter C120 W RayMarine 2011 with 2017 charts for Panama to South America.
- ST70 Color controlhead (rotary rudder reference sensor included) 2011
- Autopilot X-30 CorePack 2011
- Radar RayMarine 2011
- GPS (2x) GPS Sensor 125 Plus AIS System 2011
- VHF receiver, Radio/CD player (old) and VHF Raymarine 2180 + 2 Handheld Radios 2011
- Honda Marine 2000 Watts 220 – 12 Volts
- 2000 W Inverter (12 / 220 Volts)
ELECTRICAL SYSTEMS
- Main 12V electrical panel without PMMA door on port side of salon next to companionway
- Ampmeter, voltmeter, circuit breakers, back lighting, water gauge, 12V outlet
- 2 Deep Cycle AGM engine start batteries: 12 v- 110 Amp in 2011
- 4 Deep Cycle AGM house batteries: 12 v-140 Amp in 2011
- Battery charge splitter
GALLEY
- New Galley in salón. Literally ripped out the old galley and built a modern more functional galley
- New granite countertop in 2015
- Double s/s sink and Storage under sink
- 3 burner stove / oven with grill (LPG)
- 12V fridge 130 liter / 4.6 cu ft
TENDER
- 10.5 ft Hard bottom Dinghy
- 10.5 ft Soft bottom Dinghy
- Two Tohatsu Outboards. 10 HP and 3.5 HP (2 stroke)
- Two 2-person Kayacs
- 4 person liferaft
BOW
- T-shape foredeck seating area with generator locker
- Generator is a 2 stroke Honda Marine 2kW almost new
