The Lagoon 380 is reliable, innovative and fast, easy to handle and comfortable both at sea and at anchor. With approximately 700 units built to date, the 380 is the smallest of the Lagoon range and it holds the cruising catamaran world record.
This model has a simple, efficient deck layout with wide side decks and a rigid walkway on the trampoline. The cockpit provides a comfortable, outdoor living area to entertain family and friends.
The interior layout can be customized to include either three or four cabins and two heads. There is 360 degree visibility and great natural light from the large hull windows in the salon.
See the full specs for standard equipment. Many options are also available!
Call Little Yacht Sales for pricing information and let's discuss building you a NEW Lagoon 380 today!
Boat NameNEW Lagoon 380
SpecsKeel: Fin
Hull Shape: Catamaran
DimensionsLOA: 37 ft 11 in
Beam: 21 ft 5 in
Maximum Draft: 3 ft 9 in
Displacement: 16005 lbs
Bridge Clearance: 56 ft 10 in
Dry Weight: 16005 lbs
EnginesTotal Power: 42 HP
Engine 1:
Engine Type: Inboard
Engine/Fuel Type: Diesel
Drive Type: Sail drive
Engine Power: 21 HP
Engine 2:
Engine Type: Inboard
Engine/Fuel Type: Diesel
Drive Type: Sail drive
Engine Power: 21 HP
TanksFresh Water Tanks: 1 (79 Gallons)
Fuel Tanks: 2 (26 Gallons)
AccommodationsNumber of heads: 2
Manufacturer Provided DescriptionIn 2003, Lagoon, a member of the Boat division of the Bénéteau Group, became the world’s biggest builder of cruising catamarans due to its production system, its distribution network and its user feedback. All Lagoons bear the VPLP (Van Peteghem Lauriot Prévost) signature, the most successful firm of naval architects to date in the catamaran sector.
LAGOON 380 Is…
The undisputed world champion in its category (more than 700 boats delivered in 2013) and is still going strong. It's fast, easy to maneuver, safe and has a legion of fans spread across the world's oceans.
LAGOON 380 Means…
- Enjoying life on the high seas in a seaworthy craft.
- Enjoying life in port on a comfortable, welcoming boat.
LAGOON 380 ABOVE DECK…
You can move around easily and safely thanks to wide side decks and a rigid walkway on the trampoline.
- Transom platforms provide easy access to the sea and dinghy.
- The cockpit is a real outdoor lounge area.
LAGOON 380 BELOW DECK…
- Saloon and cabins are bathed in natural light (large hull windows).
- There is 360° Vision in the rounded saloon.
- The galley located between cockpit and saloon.
- The engine compartments are far from the living areas and perfectly insulated.
AccommodationsAvailable Versions
- 3-Cabins, 2-Heads
- 4-Cabins, 2-Heads
General Information
- Interior woodwork in marine plywood and Alpi Walnut
- Asburgo laminated floor
- Fabric-covered plywood ceiling panels or fiberglass liners in cabins and heads
- Fabric-covered plywood on hull liner in cabins
- Polyester ceiling
Standing Headroom
- Salon: 2.12m/6’11”
- Cabin: 1.90m/6’3”
- Head: 1.94m/6’4”
Mattress & Upholstery
- Marine mattresses made of multi-layer alveolar foam with several densities
- Mattresses treatment: anti-microbial, anti-bacterial, non-allergenic, anti-dust mite
- Standard upholstery as indicated on Lagoon sample book
- Blackout curtains in the cabins and salon
- Synthetic fabrics adapted to marine environment:
- Washable
- U.V. resistant
- Water repellent, with anti-stain treatment
Salon (Both Versions)
- Sliding door and window with aluminum locker for the access to the cockpit, can be locked open or closed
- (6) Person, varnished salon table, exchangeable with the optional polyester table from the cockpit
- (2) Benches, one in curve
- Lockers under the bench
Chart Table (Both Versions)
- Panel for navigation instruments
- Desk with flaps
Galley (Both Versions)
- Long galley on aft starboard
- Compact countertop
- Double large S/S sink with hot/cold mixer tap
- Cupboard under sink
- 3-Burners stove and enameled gas oven
- Waste bin
- Cutlery drawer and cupboard
- High cupboard, 2-doors
- 12V Electric fridge (184L)
Starboard Hull in 3-Cabin, 2-Head Version
Cabin:
- Double berth with front access
- Opening deck hatch
- Opening hull porthole
- Fixed hull window
- Various types of storage:
- Cupboards
- Wardrobes
- Shelves
Head:
- Composite countertop
- Washbasin with hot/cold mixer tap
- High cupboard, doors with mirror
- Separate shower with Plexiglass door
- Anti-skid diamond floor
- Big size manual toilet
- (1) Opening deck hatch
- (1) Fixed hull window
Portside Hull in Both the 3-Cabin & 4-Cabin, 2-Head Versions
Aft Cabin:
- Double berth with front access
- (1) Opening deck hatch
- (1) Opening hull porthole
- (1) Fixed hull window
- Various types of storage:
- Cupboards
- Wardrobes
- Shelves
Shared Head:
- Composite countertop
- Washbasin with hot/cold mixer tap
- High cupboard, doors with mirror
- Shower with Plexiglass door
- Anti-skid diamond floor
- Big size manual toilet
- (1) Opening deck hatch
- (1) Fixed hull window
Forward Cabin:
- (1) Trapezoidal berth
- (1) Opening deck hatch
- (1) Opening hull porthole
- (1) Fixed hull window
- Various types of storage:
- Cupboards
- Wardrobes
- Shelves
Starboard Hull in the 4-Cabin, 2-Head Version
- Same as the Portside Hull in the 4-Cabin Version
Construction - Polyester and high quality anti-osmotic resin
- Hull and deck laminated by infusion
- Balsa core hull, solid laminate under water line, white gel coat
- Balsa core bridge deck and deck
- Laminated marine plywood bulkheads
Sails & RiggingSails
- (1) High roach mainsail in Dacron with battens
- (1) Furling genoa in Dacron with UV protective strip
Standing Rigging
- Anodized aluminum mast put on the roof
- Single spreader rig
- Anodized aluminum boom
- (2) Encased shrouds
- (1) Forestay shroud on transversal cross beam
- (2) Adjustable lazy-jacks
Running Rigging & Hardware
- (1) Mainsail double purchase halyard
- (1) Genoa halyard
- (1) Mainsail sheet led back to helm station with adjustment pulley and track at the bottom of the cockpit
- (2) Genoa sheets led back to helm station on port side
- (2) Mainsail reef lines
- (1) Fixed main sail outhaul
- (1) Mainsail topping lift
- (1) Genoa furling line
- (1) Winch on roof for genoa sheet
- (1) Winch on roof for halyards
- (1) Winch handle with holder
- (2) Adjustable genoa sheet travelers
- (1) Weather vane windex
Deck LayoutMooring
- Composite longitudinal crossbeam with integrated chain run and mooring cleats
- (8) Mooring cleats
- 12V/1000W Electric anchor windlass on deck, horizontal gypsy (10mm chain) in anchor locker
Deck
- Bow trampoline with knot-less nylon netting
- Access through opening deck hatches with lock
- Stainless steel stern pulpits with buoy and flagpole brackets
- Aluminium stanchion bases
- Double stainless steel lifelines
- Stainless steel coachouse-mounted handrails
- Lifeline gates
Cockpit
- Large cockpit, functional as deck salon, direct access from port transom (Hard top bimini is optional)
- Bench with locker
- Self-draining cockpit
- Gas storage locker (2 bottles)
- Wooden coffee table (Removable polyester dinner table is optional)
Helm Station
- Steering station on roof bulkhead with:
- Engine controls
- Engine instrumentation
- Compass
- Space for electronics
- Double helmsman bench
Transom
- Hot/cold deck shower on portside
- S/S telescopic swim ladder with fixed handles on portside
- Access to engine compartments through hatches in the aft transom
ElectricalPower Circuit
- (2) Alternators, 12V 80AH
- (2) Start Batteries, 12V 110A
- (2) Service Batteries, 12V 140AH
- Breaker for Batteries under the berth in the aft starboard cabin
Distribution Electric Panel
- 12V General distribution panel at the chart table
- Voltmeter, ammeter, circuit breakers, panel lighting, cigarette lighter
Lighting
- 12V LED outside lighting
- 12V LED inside lighting
- Navigation lights
- 12V Engine compartment lighting
PlumbingFresh Water Circuit
- Fresh water tank (300L) with gauge at the chart table
- Fresh water circuit with (1) main water group in the forward portside cabin
- 22L Water heater, starboard engine exchanger
Grey Water
- Shower and washbasin drain to grey water tank and automatic pump
Black Water
- (1) Holding tank (83L) in each hull (total 166L)
Bilge Pump Circuit
- (1) Manual bilge pump in aft cockpit
- (1) Automatic bilge pump in each hull
Engines - (2) Diesel Yanmar3YM20 sail-drive engines
- Fixed 2-Blade propellers
- Seawater filter
- Mechanical engine throttles at the helm station
- Air extraction
- Ventilation of the engine compartment: natural suction and forced extraction in the aft transom
- Sound-proofing of the engine compartment
- Access to engine compartment from the hatch on transom
- Fuel circuit:
- (2) Rotomoulded tanks, 26 US gal each
- Fuel filter
- Fuel shut off valve
- Gauge at the general distribution panel
Optional Equipment - Talk to the Brokers at LYS about all the Optional Features available to customize your NEW Lagoon 380!
