2023 Riva Super Corsaro 102

Overview

Builder: Riva

Model: Cosaro Super

Year: 2023

Length Overall: 30.26m (99ft 3in)

Beam: 6.7m (22ft)

Draft: 2.4m (7ft 8in)

Hull: GRP

Deck: Teak

Speed: 28 knots

Designer: Officina Italiana Design

Guests: 10 in 5 Cabins

Crew: 5 in 3 Cabins

Flag: Jamaica

Tank Capacities

Fuel Tanks: 9,000 L (2378 US Gals)

Water Tanks: 1,320 L (349 US Gals)

Grey Water: 330 L (87 US Gals)

Black Water: 330 L (87 US Gals)

Main Engines

Engines: 2 x MTU 16V 2000 M96L

Power: 2,638 HP / 1939 kW Each

Port Engine Hours: 520

Starboard Engine Hours: 520

Gearboxes: ZF 3070 V 2.520:1

Range

Max Speed (28 knots): 250 nm

Cruising Speed (24 knots): 300 nm

Economical (16 knots): 380 nm

Generators / Electrical

Output: 120/240 Volts

2 x 35kW Kholer Generators

Port Generator Hours: 840

Starboard Generator Hours: 892

2 x Generator Mastervolt battery charger

Shore Power: 480 V 3-Phase 60Hz

Shore Power Cord: Glendinning

ME Batteries: 4 x Faam 12V

Starter Batteries: Faam 12V

Service Batteries: 12 x Faam 12V

Battery Chargers: 2 x Mastervolt 24V / 75 Amp

Lighting throughout: 24V

Three /monophase isolation transformer: 25KVA (2)

Engine Room

2 x Condaria Super tropical air conditioning (3 compressors each)

Hydraulic bow thruster: 50 hp

Hydraulic stern thruster: 40 hp

BCS Steering system

Alfa Laval fuel depurator

UVA Water maker: 180 L/H

Additional water maker: 180 L/H

Underwater silenced exhausts

2 x Main engine fuel filters

Electric bilge pump

2 x Ventilation fans

2 x Generator fuel filters

2 x Water filters for main engines

2 x Water filters for generators

Electric pump for bilge drainage (engine room)

Emergency bilge suction pipe (engine room) through engine cooling pump

Multipurpose electric pump (bilge, grey water, black water)

Electric WC system with fresh water

Stabilizers

Gyroscopic stabilizers

Stabilizer fins: underway and zero speed

Interceptor trim stabilizers

Communication and Navigation

KVH TracVision TV8: sat TV

2 x Simrad fixed VHF

4” Urania compass

Simrad NAC3 autopilot

4 x Simrad NS024 Evo3s GOS

Simrad Halo 72nm radar

Simrad IS42 speed log

NMEA Arimar weather station

Simrad NAIS500 AIS

Starlink Pepwave Internet

NAVIOP Monitoring system

FLIR Camera

Fire Extinguishing & Safety

FM200 fire extinguishing system

Automatic shutdown of engines and safety over-ride

Smoke detection alarm system

20 x Lifejackets

2 x 10-person life rafts

2 x Life rings

Deck

4 x Underwater lights at transom

2 x Aft cleats for tender mooring

13mm Anchor chain

137.5m Anchor chain

2 x Anchors 105kg each

Upgraded 3.5kW winches

Galley & Laundry

Miele 4 x hob KM7684FL

Miele oven

Miele microwave

Miele dishwasher

Samsung stainless steel fridge / freezer

Flybridge Isotherm ice maker

34 Bottle Summit wine cooler

Miele coffee bar

Flybridge Fridge / Freezer: Isotherm

Miele 9Kg WRC870WPS Washing machine

Miele 9Kg TCR790WP Dryer

Audio Visual

A/V Package Premium Control Area A

Main Salon: Samsung 75” LCD/LED with Sony Blu-Ray and Apple TV

Master: Samsung TV + Apple TV

Guest Cabins: Samsung TV + Apple TV

Crew Area: LG TV + Apple TV

Exterior Music: Audio Fusion BT/SAT/Radio

Guest Music: Audio Fusion BT/SAT/Radio

Remotes: RTI App on Ipad

Tender & Toys

5 Jet Rib

Jetski

2 x Seabob Riva Edition
