2004 Lazzara Yachts 80 Skylounge M.Y.

2004 80' Lazzara Open Bridge

RENDEZVOUS is a well-equipped vessel that has been maintained with an open checkbook inside and out.

Layout and Accommodations

RENDEZVOUS features the preferred open bridge layout with:

• 3 Staterooms (Master & Two VIP)
• Captain's & Crew Quarters

Five Staterooms - Six Heads

Loaded with options including an ABT Trac Stabilizer System and Jacuzzi on the bridge.

Recent Service & Upgrades

• 2018: Full 1,000 Hour Service performed on both CAT C30 Engines. Stabilizer System serviced. Custom power blinds installed at lower helm. New interior & flybridge carpet installed.
• 2017: All new exterior cushions, new canvas, and fridge on top deck.
• 2015: Installed 3 new A/C units.
• 2013: Refitted with new interior roof/wall panels, new floors, new mattresses, new TV/sound system, new anchor chain, new shaft seals, and cutlass bearings.

Included: 2 x Kawasaki 3 Seater Jet Skis - 2017 Model STX 15F

Vessel Walkthrough

Once aboard RENDEZVOUS, you will discover both the exterior and interior of this luxury motor yacht will make you feel at home. The spacious salons and state rooms are equipped with state-of-the-art electronic technology. Enjoy air-conditioned comfort or the fresh air from the double door aft deck slider. RENDEZVOUS is outfitted with a variety of equipment for you and your guests to enjoy many water activities, including dual 3-seater jet skis and a full jacuzzi on the flybridge.

Salon

You enter the salon through two large stainless steel double doors. The salon is bright with plenty of lighting and large windows throughout. The wood flooring runs the entire length of the main deck, complemented by high gloss cherry wood interior.

A cherry wood table sits in front of the sofa. The salon has an elegant feel with upholstered valances and pull-down Duette shades. Overhead is a cherry wood oval surrounded by eight halogen mini spots, with thirteen additional halogen mini spots throughout the salon.

Dining Salon

The dining table seats comfortably six, featuring a high gloss wood top with a cherry wood pattern. A buffet with three cabinets and three drawers is located aft of the table. Cherry wood continues along the port side into two built-in china cabinets with interior lighting. Below are cabinets and drawers for table linens and plate ware.

On the starboard side is another buffet with cabinets and four drawers, serving as a divider for the stairs to the lower deck and accommodations. Above is a triple glass door cabinet for cocktail glasses with interior lighting. A large oval dome light is above the dining room table, surrounded by cherry wood trim.

Galley

Entering the galley via a sliding cherry wood pocket door, you will find a large country kitchen-style galley. To port is a 4-door pantry with 7 shelves. Starboard are the curved open steps leading up to the flybridge. Next forward is the on-deck powder room with a toilet, marble floor, marble countertop, and a curved front cabinet.

In the center of the galley is an island with a granite countertop, stainless steel sink with a removable spray faucet, instahot water dispenser, Frigidaire stainless steel dishwasher, and four cabinet doors for storage. Aft is a Kitchen Aid Superba double door stainless steel refrigerator with water and ice through the door, a Kitchen Aid Superba stainless steel convection oven, a Kitchen Aid four-burner ceramic cooktop, and a GE Spacemaker stainless steel microwave with light and exhaust fan below. Storage is in three cabinets and three drawers below the countertop.

Next forward is a Kitchen Aid stainless steel trash compactor and two Sub Zero freezer drawers. Above the appliances are twelve additional cabinets for storage and dishes. A raised dinette with seating for six features a granite table top on two fluted column bases. A large windshield provides ample light and an open airy feeling. The sole of the galley is bamboo wood plank with rope lighting. An LCD flat screen is also present. Just forward is a stairwell leading to the crew area.

Foyer

Going down the carpeted steps leads to the master and guest accommodations. The sole is marble, and looking aft, you will see a curved two-door cabinet with a high gloss top and special lighting for a sculpture or artwork.

Across the foyer are a six-shelf linen locker, a Bosch clothes washer, and a Bosch clothes dryer.

Master Stateroom

Entering through the main foyer and aft through a double door entry leads to the master stateroom. In the center is a king-size berth with five large drawers below. On both port and starboard are free-standing nightstands with two drawers each. Twin fixture sconces are wall-mounted above each nightstand. An upholstered headboard and large mirror are above between the lamps. Overhead is a mirrored panel with eight halogen mini spots in the surrounding cherry wood molding.

Starboard, there is a chest of three drawers with three open shelves above. Moving forward is a desk/vanity with a single drawer below. Two sliding screens cover oval port windows, providing plenty of exterior lighting.

There are three more matching drawers with a two-drawer cabinet and two open shelves furthest forward. On the port side, there are dual three-drawer chests with open shelves above. A two-person settee with storage under the cushion is between the two chests of drawers. Above the settee are two Soji screens concealing two large port windows for ample exterior lighting.

On the forward bulkhead is a mounted LCD TV with surround sound stereo/DVD/CD player.

Master Stateroom Head

The huge his and her marble master head resembles a luxurious home found ashore. The flooring is slab marble. The vanity is made of cherry wood with two china sinks on a marble top with a waterfall edge. Below the countertop are seven cabinet doors and three drawers. Above are five mirrored panels, two of which are medicine cabinets.

The tub is the main feature of the head, featuring a Kohler Whirlpool Jacuzzi with a full clear glass enclosure and a door in the center of the tub. There is a Microphor model toilet and a large mirrored door opening to a four-shelf linen locker.

VIP Port Guest Cabin

The queen berth in the Port VIP Guest Stateroom is walk-around on three sides, utilizing half the beam of the yacht to its best advantage. The base of the berth has four large drawers, rope lighting, and rope trim molding. Above the upholstered headboard is an inset mirrored area with a two-door cabinet fore and aft. Above are two opening stainless steel portholes, Duette shades, and reading lights.

Aft of the berth is a two-drawer nightstand with telephone and light switches. Next forward is a cedar-lined lighted hanging locker with a mirror on the exterior of the door. At the foot of the berth in the forward corner is a curved corner cabinet with two doors below, two open shelves, and an LCD TV above. This stateroom features high gloss cherry wood decorative paneling and seven mini spotlights above.

VIP Port Guest Cabin Head

The Guest Head includes a china sink, Grohe fixtures, bull-nosed marble countertops matching the sole, and a Microphor china toilet. The stall shower has a clear glass door with sidelight, a fiberglass stall shower, and a handheld or wall-mountable Grohe fixture. This head also includes an exhaust fan, an AC outlet, and four overhead mini spotlights.

VIP Starboard Guest Cabin

The VIP Starboard guest cabin has the same queen-size berth and walk-around on three sides. The base of the berth has four large drawers, rope lighting, and rope trim molding. Above the upholstered headboard is an inset mirrored area with a two-door cabinet fore and aft. Above are two opening stainless steel portholes, Duette shades, and reading lights.

Aft of the berth is a two-drawer nightstand with telephone and light switches. Next forward is a cedar-lined lighted hanging locker with a mirror on the exterior of the door. At the foot of the berth in the forward corner is a curved corner cabinet with two doors below, two open shelves, and an LCD TV above. This stateroom features high gloss cherry wainscoting and seven overhead mini spotlights.

VIP Starboard Guest Cabin Head

Entering the Guest Head, you will see a china sink, Grohe fixtures, bull-nosed marble countertops matching the sole, and a Microphor china toilet. The stall shower has a clear glass door with sidelight, a fiberglass stall shower, and a handheld or wall-mountable Grohe fixture. This head also includes an exhaust fan, an AC outlet, and four overhead mini spotlights.

Captain's Quarters

The Captain's Quarters is accessed from the common area and features a queen-size berth against the outboard bulkhead. Below the berth are two storage drawers and rope trim molding. Above the berth are four cabinets with a mirrored inset area centerline. Above is a shelf with two portholes and blinds. At the foot of the berth is an LCD flat panel TV and a full-size lighted hanging locker with a mirrored door.

Inboard of the berth is a two-drawer nightstand with a reading lamp above.

Captain's Head

Entering the Captain's Head, you will see marble flooring, a china sink with a marble top, a Grohe faucet, three mirrored medicine cabinet doors, and a Microphor head. The fiberglass stall shower has a seat, a bi-fold glass door, a handheld or wall-mountable Grohe fixture, a light, and an exhaust fan. This head also includes three halogen mini spots overhead.

Crew Cabin

The Crew Cabin features two bunk beds with storage below and a screened overhead deck hatch. To starboard are four cabinets above two large cabinets below. The crew cabin also has a cedar-lined hanging locker with a mirror on the outside of the door.

Crew Head

Entering the Crew Head, you will see marble flooring, a china sink with a marble top, a Grohe faucet, three mirrored medicine cabinet doors, and a Microphor head. The fiberglass stall shower has a seat, a glass door, a handheld or wall-mountable Grohe fixture, a light, and an exhaust fan. This head also includes three halogen mini spots overhead.

Flybridge

The spacious flybridge is accessed from either the aft deck or the curved steps in the galley area. All electronic controls, gauges, radar & plotting screens are convertible from being totally concealed under a completely flat panel when not in use, or brought into the upright position by hydraulic control lift.

Aft of the steering station is a roomy entertainment area with several seating stations: a custom fabricated quarter-moon inlaid wooden wet bar backed by a barbeque grill. An icemaker is conveniently located alongside the wet bar, with refrigeration behind the helm's bench seat. There is ample storage, and a roomy Jacuzzi is also available for relaxation in the sun.

Aft of the entertainment area on RENDEZVOUS is the storage area for a large tender, as well as the life raft.

Electronics and Additional Information for Flybridge

• Custom designed windscreen
• Custom arch with pre-engineered locations for electronics, antennas, radar, lighting, horns, and navigational lighting
• Helm chairs (one single, one double)
• Peninsula shaped bar with varnished wood countertop, sink, and electric grill on the port side
• Refrigerator under aft bar counter
• Corian counter forward of the bar on the port side with refrigerator underneath
• Adjustable sunpad lounging area
• Outdoor seating group, split into port and starboard sections with bright work table for each section
• Storage for yacht dinghy
• Access sliding hatch to main deck level
• Access hatch to aft deck via ladder
• Fully instrumented console for operation to include all controls and accommodate electronics
• Control for bow thruster
• Electronic engine controls, combination clutch and throttle
• Hydraulic steering, power assisted
• Access to stairs descending to main deck
• Hydraulic davit with remote control, starboard side concealed into styling line, with telescopic and power rotation features
• Stainless steel dinghy chocks convert to aft bridge deck guard rails
• Controls for house sound system

Aft Deck

When boarding onto RENDEZVOUS from the side aft deck, you may choose to step down to the swim platform. Here you will gain access to an immaculate engine room, the starboard storage pod containing dive gear & air compressor, or the portside storage pod which accommodates the jet ski.

The aft deck has comfortable seating for six guests with a built-in banquette aft (which doubles as a storage locker) and four teak chairs surrounding a glossy wooden dining table. Access to the flybridge is via a stainless ladder. There are hinged fiberglass boarding on both the port and starboard sides of the ship.

Aft Sport Deck

Descending the stairway on the aft deck leads to the Aft Sport deck, where you will have access to the engine room and the two pods on either side containing the two Jet skis. The aft sport deck features a fresh water wash down, a hot and cold handheld shower, dockside water connection, fuel fill, shore power outlet, and a walk-in engine room with inspection port.

Crew Lounge

• Veneered desk with drawers, wood top
• Book shelf, acrylic
• Reading light
• Receptacle, 120 volt (2)
• Washer/dryer
• Telephone outlet
• Computer outlet
• Access to lower forward bilge area
• Carpeting
• Desk chair

Electronics and Navigation

• Sidepower bow thruster controls
• Brooks & Gatehouse HS2000 depth speed, multi readout
• Tilt & pan controls for engine room camera
• Windshield wipers and washers
• (2) Northstar 952X Simrad radar (12" screen at lower helm, 17" screen on flybridge)
• Air Horns
• ITT Jabsco Searchlight and controls
• KVH Tracphone
• Windlass Controls at Helm
• KVH Satellite
• Stabilizer controls at Helm
• Delta T fan speed controls at Helm
• Sea Tel Trac 92 SAT TV system
• Extron DVS video scaler
• Cell phone handset
• Sat phone handset
• ISIS ship board monitoring system
• (6) SAT TV receivers
• Robertson AP20 Auto pilot w/AP21
• Simrad VHF Radios
• (2) Extron VSC 100 digital video converters
• MTU Blue Line electronic controls
• 120 volt TV amplifier
• KVH electronic compass
• HP Pentium 4 Navigation computer with Noble tech software package
• Furuno FCV 582L color depth sounder
• Telephone
• Panasonic PBX telephone system with SAT and cell phone interface
• (2) Auxiliary speakers for VHF radios
• Raytheon 430 loud hailer with forward and aft speakers
• 15 VEI daylight viewable color monitor

Electrical System

• 24 volt Glendinning cable master
• 100' 100 amp 240 volt shore cord
• (2) Digital AC frequency meters in Engine Room Panel
• (4) Digital AC amp meters in Engine Room panel
• (4) guest battery switches
• 24 volt battery charger
• (4) Deka Group 24 maintenance-free batteries for thruster and windlass
• (2) 8D main engine batteries
• Charles Ind. 24 KVA isolation Transformer
• (2) Generator battery switches
• Electronic Battery switch
• Electrical bonding system
• (2) 21 KW Onan Generators
• Charles Ind. 30 amp 24V battery charger for thruster and windlass
• 12 V battery charger
• (2) 4D generator batteries
• (2) Digital AC voltage meters in Engine Room panel
• Digital DC volt and amp gauge with (6) selector points
• Charles Ind. Smart Y converter box
• International Navigation lights 24V
• Alarms for engines, reduction gears, bilges, and generator

Engine and Mechanical Equipment

• ABT Trac Stabilizer System
• 35 gallon clean oil storage tank
• 35 gallon waste oil storage tank
• Head Hunter water tank sentry connected to ISIS monitoring systems
• Anti surge tank for water system
• Microphor toilet system (6 toilets)
• Head Hunter waste tank Sentry connected to ISIS monitoring system
• Volt air handles- lower decks with heat strips
• Cruise air SMX controllers throughout
• (2) 24 volt Pod door hydraulic pump units with remote openers
• Airsep crankcase ventilation system
• Work bench with vise on top of starboard generator
• Sea strainers for main engines and generators
• Automatic and manual Fireboy fire protection system
• Aircraft type stainless steel fuel lines
• Blue Line MTU electronic control system
• Underwater exhaust with idle bypass
• Engine Room mechanical gauges
• Chrome package for engines
• Dripless shaft seals
• Electronic Blue Line engines synchronizers
• 200 Gallon holding tank
• Sea Recovery 1200 GPD watermark with fresh water rinse
• Rule 24 volt retrieval winch for Jet Ski
• Fresh water wash down system in engine room
• Stainless steel rudders
• Dual Racor 1000 Fuel Filters with Vacuum gauges and stainless steel braided hoses
• Manual engine room gauges
• 40 gallon hot water heater
• 3 hp 240 volt main bilge pump manifold to three bilge compartments
• (3) Automatic 24 volt bilge pumps
• Diamond plate sole in Engine Room
• AC and DC fluorescent Engine Room lights
• (2) Oiless air compressors
• (2) 120V air compressors 42,000 BTU, 30,000 BTU, and (2) 24,000 BTU reverse cycle Cruiseair compressors
• Acoustical and thermal insulation in Engine Room
• Tuthill 120V oil change pump
• Hynautic power steering pump off port engines
• Bell and Gossett 120V AC hot water circulating pump
• 220 volt Sealand diaphragm type sewage
• Engine Room camera
• Media filter for water system
• 120 volt chemical-free U-16 ozone generator for water system
• Sleipner Side Power 48 volt 20hp Progressive Thrust bow thruster
• Rolla five blade propellers
• 3" Aquamat 2 HS main prop shafts
• Discharge pump
• 220V AC raw water air conditioning pump
• Head Hunter Mach 5 230V pressure water pump
• Par Max 3, 24 volt backup pressure water pump
• (2) Storage cabinets in Engine Room
• (2) Delta T frequency controlled axial Engine Room fans

Additional Features

• (2) Brand new Kawasaki 4 stroke Jet Skis
• (2) Brand new pod doors to hold Jet Skis

Exclusions

While every effort was made to list all pertinent included equipment aboard RENDEZVOUS, there are some personal belongings aboard. Prospective purchasers should assume any item not specifically mentioned herein will not convey at closing.
