DETAILS OF RECENT WORKS AND REFIT:
2016 Full external Painting of top sides including superstructure.
2 New generators
External fabric replaced on all upholstery
2018
Sand blast hull below waterline to gel coat and re coated
2019
8 New domestics batteries
GENERAL:
6 months on the hard inside a building every winter since 2007
Full boat/engine service every winter since built
DETAILS OF RECENT WORKS AND REFIT:
2016 Full external Painting of top sides including superstructure.
2 New generators
External fabric replaced on all upholstery
2018
Sand blast hull below waterline to gel coat and re coated
2019
8 New domestics batteries
GENERAL:
6 months on the hard inside a building every winter since 2007
Full boat/engine service every winter since built
In exceptional condition for age as same Captain since 2007
Full history and every bill available.
Specs:
Builder: Alfamarine
Designer: Andre Bacigalupo/Owner's Design
Dimensions
LOA: 78.0 m
Beam: 5.90 m
Maximum Draft: 1.20 m
Displacement: 42000 kgs
Engines
Engine Brand: 2 x Caterpillar
Engine Model: C32 ACERT Engine/Fuel Type: Diesel
Engine Power: 1800 HP
Tanks
Fresh Water Tanks: (329)
Fuel Tanks: (1319)
Accommodation
Number of cabins: 3
Number of heads: 7
Dimensions
Beam: 19.4
Max Draft:
4 Displacement: 42
Engines
Total Power: 1800
Cruising Speed: 30
Max Speed: 40
AUXILIARY MACHINERY & ELECTRICAL SYSTEM
Generators: 2 x 16 Kw Electric generators
Batteries: Service batteries: 630 ha.
24V Start battery: 420 ha 24V
Automatic batteries charger
TANK CAPACITIES (APPROXIMATE)
Fuel: 6,000 litres (1,585 US gallons)
Water makers: Water maker producing 130 lt/hr Water: 1,500 litres ( 396 US gallons)
SAFETY & SECURITY EQUIPMENT
Safety: 2 x Life rafts for 8 persons each Life buoy
12 x fenders
Alarms: Alarm system for portholes position open-closed
Centralised alarm system for all bilge compartments
Fire Fighting: Co2 extinguisher system with remote control in the aft deck
Water pump for fire fighting and anchor chain Washing
Security: 4 x submersible bilge pumps 24V
ANCILLARY EQUIPMENT
Steering System: Arneson trim control with position indicator
Bow Thruster: 1 x 30 Hp Bow thruster
Rudder Angel Indicator
Fuel Separator & Filters: Fuel water-separator filters present Stabilizers: Hydraulic flaps
Air Conditioning: Hot and cold air conditioning (BTU 60.000) in every space with individual temperature regulation.
Chilly water circulation system Boiler: Water heater 80 lts WC’s:
Tecma Vacuum flush system, 4 units
COMMUNICATION EQUIPMENT
VHF Radiotelephones: Radiotelephone Furuno FM-8500 with distress facility.
Telephone Exchange: Telephone exchange system with handset in each room and two inlet external lines
Intercom System: Intercom for mooring operation Raymarine
NAVIGATION EQUIPMENT
Magnetic Compass: Magnetic compass type Riviera 6"
GPS: Furuno GPS antenna receiver
Automatic Pilot: Automatic-pilot AP 3003 Gold
Radar: Furuno Radar with an antenna of 4ft 6Kw and a range of 64 miles
Echo Sounder: Deep sounder Raytheon ST60
Chart Plotter: Furuno Plotter with c-map cartridges
Navtex: Furuno NavNet with Two colour LCD display with 10.4
Weather Fax: Weather station: clock, barometer, thermohygrometer
DECK EQUIPMENT
Anchor Windlass: 1 x 2.500kW anchor windlass
Ground Tackle:
Anchors: 1 x 25kg Bruce anchor Chains: 1 x s/s 12mm anchor chain of 90m
Boat Crane & Davits: Electrical crane for launching
Swimming Platform: Electrical swimming ladder
External shower on both stern and foredeck
Passerelle & Side Ladders: Retractable passarelle with 2 extensions of 4m in total length Awning: Canopy covering the sundeck
TENDERS & WATER SPORT EQUIPMENT
Tenders: Avon Jet RIB with 4 stroke Engine
Sports equipment: A set of snorkels, pair of water skis
AUDIO/VISUAL ENTERTAINMENT SYSTEMS
Televisions: 1 x APPLE LCD television 30” with lifting mechanism in salon
1 x Television APPLE LCD 37”, combined DVD/VCR and satellite decoder in Owners cabin
2 x Tv LCD APPLE 15” in guest cabins 1 x Television LCD 15” with satellite decoder in galley Satellite Television: Satellite television antenna receiver “Navisystem MST 103”
ACCOMMODATION
Owner: Double Master cabin with en suite shower facilities. Vanity desk (port) with crystal top. Sofa for two persons with coffee table. Guests: 2 x Twin guest cabins port & starboard with en suite shower facilities Crew: 2 x Twin crew cabins with bunk beds and shared bathroom with shower
DOMESTIC EQUIPMENT
Galley: NEF Electrical oven NEF Microwave oven NEF Ceramic electrical cooker with four hot plates Electrical hood with cabinet above Dish washer N. 2 stainless steel sinks Laundry: Washing machine combined with dryer Bars: Cabinet with open top and sink. Basement equipped with refrigerated wine cellar for 36 bottles, storage beside Refrigeration: Refrigerator/deep freezer with two doors full height
OTHER EQUIPMENT
Sun roof: Retractable fibreglass roof by electrical system Deck Furniture: Sofa with table plus three poufs or an additional sofa facing aft
MATERIALS
Hull Materials : GRP
Superstructure Materials : GRP
Deck Materials : Teak Laid
CLASSIFICATION
RINA certified
